3/4" COMBO PARTICULATE FILTER MOISTURE TRAP LUBRICATOR REGULATOR & AUTO DRAIN
3/4" COMBO PARTICULATE FILTER MOISTURE TRAP LUBRICATOR REGULATOR & AUTO DRAIN
Key features
- HEAVY DUTY MID FLOW 3/4" COMBINATION FILTER-REGULATOR-LUBRICATOR
- W/ GAUGE & INTERNAL FLOAT DRAIN.
- 250 PSI MAX CAN HANDLE 1 STAGE AND 2 STAGE APPLICATIONS
- 3/4" FEMALE NPT INLET X 3/4" FEMALE NPT OUTLET
- 7 - 225 ADJUSTMENT PRESSURE
HEAVY DUTY MID FLOW 3/4" COMBINATION FILTER-REGULATOR-LUBRICATOR W/ GAUGE & INTERNAL FLOAT DRAIN. 250 PSI MAX CAN HANDLE 1 STAGE AND 2 STAGE APPLICATIONS 3/4" FEMALE NPT INLET X 3/4" FEMALE NPT OUTLET EQUIPPED WITH WALL MOUNTING BRACKET FILTER SPECS: 3/4" 250 PSI MAX 5 MICRON FILTER INCLUDED AUTO DRAIN ( INTERNAL FLOAT DRAIN LOCATED BOTTOM PARTICULATE FILTER METAL BOWL) 2.7oz BOWL CAPACITY ( METAL BOWL) VISUAL SIGHT GLASS 140 CFM FLOW RATE REGULATOR SPECS: 3/4" 140 CFM FLOW RATE EQUIPPED WITH BACK MOUNT PRESSURE GAUGE 7 - 225 ADJUSTMENT PRESSURE 250 PSI MAX LUBRICATOR SPECS: 3/4" -MAX PRESSURE: 250 PSI -INLET OUTLET: 3/4" INLINE -OIL FILL ADJUSTMENT TO REGULATE OIL FLOW TO THE AIRLINE -5.1oz OIL CAPASITY ( METAL BOWL) -VISUAL SIGHT GLASS OPERATING & INSTALLATION INSTRUCTIONS INCLUDED
Free shipping included. 30-day hassle-free returns.
