400w 12v/24v/48v Vertical AXIS Permanent Maglev Wind Turbine Generator MPPT Controller Free Energy High Efficiency

Key features

• Curved blade design,utilizes wind resource effectively and obtains a higher power generation.
• Coreless generator, Horizontal rotation and aircraft wing design reduce the noise to an unperceivable level in natural environment.
• Wind resistance. Horizontal rotation and triangular double fulcrum design make it only bear a small wind pressure even in strong wind.
• Rotation radius. smaller rotation radius than other types of wind turbines, space is saved while efficiency improved.
• Effective wind speed range. special control principle expended the wind speed to 2.5 ~ 25m/s, utilizes wind resource effectively and obtains a higher power generation.

Des/Model: FX-400 Started wind speed (m/s): 1.3 m/s Cut-in wind speed (m/s): 2.3 m/s Rated Wind speed (m/s): 12 m/s Security wind speed: 40m/s Rated voltage（DC）: 12V/24V/48V Rated power（W）: 400W Max power（W）: 450W Rotor Diameter of Blades（m): 0.6m Blades Height（m): 1.05m Packing size: 110x40x23cm Safe wind speed (m/s) : Max wind speed：≤40m/s， The instantaneous maximum wind speed≤45m/s Blades quantity: 3 Blade material: Fiber glass Generator: Three phase permanent magnet suspension motor Control System: Electromagnet Mount Height（m): 7~12m （9m） Generator protection grade: IP54 Work environment temperature: VAWT -25~+45℃ controller -10~+45℃ Work environment humidity: VAWT ≤90%、 Controller and inverter≤80% Altitude： ≤4500m Product assembly weight (Kg): <24Kg Yaw mode: auto up-wind Tower: Cable / Independent tower Overspeed protection: Electromagnetic brake Overload protection: Electromagnetic brake and the unloading unit
