40W 15K Variable Speed Motor with Controller, High Torque Ac Motor

Key features

• 110v High torque electric ac motor: This 110v ac gear motor provides 90w rated power, 0‑90rpm rotating speed and a 1:15 reduction ratio which brings steady and dependable industrial transmission performance
• Durable construction: This drive unit adopts die-cast aluminum alloy and 40cr alloy steel that offers great impact and corrosion resistance to sustain long-term continuous operation
• Forward & reverse operation: This gear reduction assembly supports simple forward and reverse switching, where ball bearings installed on both rotor ends ensure low-friction and smooth running status
• Efficient heat dissipation: This motor body is fitted with rear cooling holes and an internal fan which speeds up heat dispersion, alongside rounded smooth edges that improve handling safety
• Complete all in one kit: This set comes nearly fully pre-assembled containing gear motor, reducer and speed controller, whose shaft diameter equals 0.47in and net weight reaches 7.05lbs

Specifications: Material: Aluminum Alloy, 40cr Alloy Steel Process: Thermal Refining, Fine Finish, Nitrogen Treatment Reduction Ratio: 1: 15(15K) Speed Controller Speed: 0-90r/min Motor Speed: 50Hz 90-1350r/min; 60Hz 90-1650r/min Torque: About 3.8nm Power: 40W Voltage: 110V Motor Type: Gear Motor Protection Class: IP54 Noise: Around 60dB Package Size: 25*25*13cm/9.84*9.84*5.12in Base Width: 90mm/3.54in Motor Hight:117mm/4.61in Reducer Hight:41mm/1.61in Mounting Hole Distance: 73.5mm/2.89in Disk Size(D*H):34*4mm/1.34*0.16in Shaft Thickness: 12mm/0.47in Shaft Height: 28mm/1.1in Gross Weight: 4kg/8.82in Net Weight: 3.2kg/7.05lbs Package Included 1* Gear Motor 1* Reducer 1* Speed Controller Notes 1. Please check the size carefully before ordering. 2. Please connect each wire correctly to ensure that the machine can operate normally. 3. Based on industry standards, to meet the different needs of customers, please note that our motors do not include power cords. You need to purchase a power cord to connect.
