6 Digital Counter Scale CounterSESTOS C3E-R-24 AC/DC 12-24V Maximum Speed 10kcps.Programmable Timer Relay NPN and PNP inputs can be Switched. Cycle Timer,Repeat Cycle Timer has UP/Down Mode,pid Timer

Key features

• 10-Year Data Retention & High Reliability：This 6-digit digital counter relay utilizes high-precision MCU control and EEPROM memory to retain critical count values for up to 10 years, ensuring uninterrupted operation in applications where accurate and dependable counting is essential.
• Flexible Preset Scale & Counting Direction：The programmable preset counter offers an intuitive scale range and supports both UP and DOWN counting modes, enabling quick customization for batch control, length measurement, and totalizing tasks across diverse industrial processes.
• Key Lock Function to Prevent Misoperation：A front-panel key lock secures all settings against accidental changes, reducing the risk of operational errors and enhancing overall productivity in demanding workshop environments.
• Energy-Efficient Low Power Design：Engineered for continuous use, the low power consumption of this digital counter minimizes heat buildup inside control panels and contributes to long-term energy cost savings.
• Universal NPN/PNP Switchable Input：The versatile input accepts contact and non-voltage signals with simple NPN/PNP switching, allowing seamless integration with encoders, proximity sensors, and PLCs without external signal converters.

DIN Standard Panel Mount：Compact 48x48mm housing with 45x45mm cutout size, designed for flush installation in industrial control panels. Wide Counting Range & High Speed：Count range from 1 to 999999. Supports UP/DOWN counting modes with a maximum counting speed of 10 kcps. Preset scale range adjustable from 0.001 to 99.999 for precise batch control. MCU Digital Control with 10-Year Data Retention：High-precision microcontroller ensures reliable counting accuracy. Built-in EEPROM memory retains count data for up to 10 years, with user-selectable save option. Versatile NPN/PNP Switchable Input：Input supports both contact/non-voltage (NPN) and voltage (PNP) signals with simple switching. Accepts control signals (Reset, Gate) with minimum pulse width ≥5ms. External DC 12V/50mA supply available for sensor excitation. Clear Anti-Glare LED Display：PV (Present Value): 6-digit 9.2mm high-brightness red LED. SV (Set Value): 6-digit 7.0mm high-brightness green LED. Anti-glare panel ensures excellent visibility in bright environments. Easy Operation with Key Lock：Tact switches for UP/DOWN setting value adjustment. Key lock function prevents accidental setting changes and power supply misoperati
