62-23543-01 Flame Sensor for Rheem, Ruud, WeatherKing

Key features

• MODEL NUMBER:62-23543-01 Furnace Burner Flame Sensor Rod .Snug fit the Rheem Ruud, and Weatherking residential furnace models Furnace
• Replace Part :62-23543-01,62-23543-02, 62-23543-03, 62-23543-04
• Spec :The furnace flame sensor is designed to detect the flame. Termination: 1/4”male quick connect,Angle - sensor offset: 90 degree.Burner flame sensor 62-23543-01 detects when the burner flame has ignited and sends a signal to the control board to stop the igniter from operating
• PREMIUM QUALITY: Anti-high temperature,Corrosion resistance.High quality alumina ceramic insulator, High temperature flame rod material
• ATTENTION: Please consult your machine manual before ordering to make sure the replacement parts are correct

FITS Model :NORGDG, SGDG, RGDJ, RGFD, RGLG, RGLH, RGLJ, RGLK, RGLL, RGLN, RGLQ, RGLR, RGPH, RGPJ, RGPK, RGPL, RGPN, RGPP, RGPQ, RGPR, RGRA, RGRB, RGRJ, RGRK, RGRL, RGRM, RGSA, RGTA, RGTJ, RGVG, RGVH, RGVJ, 80LJ, 80LS, 80PJ, 80PS, 90RJ, 90RS, 90RT, 90TJ, 90TS, RGFE, RGFG, RGLE, RGLS, RGLT, RGPE, RGPS, RGPT, RGRS, RGRT, RGTS, SGPG, SGPNINSTALLATION STEPS STEP 1:Shut off the power to your furnace (or any other appliance), prior to making any repairs. There will usually be a light switch (toggle switch)on or near your furnace. If this switch is not present, furnaces have a dedicated breaker; locate your furnace breaker and shut your unit down.STEP 2: Remove the Sensor. Find the broken sensor. The sensor is easily accessible and typically mounted by one 1/4” hex head screw. Upon removing this screw, the sensor will slide out so that you can easily clean it. Carefully remove the sensor;STEP 3 :Remove one sensor and replace it with our new sensor. STEP 4 :Simply reconnect the wire if you’ve taken it off, remount the sensor to the burner assembly using the 1/4” screw, replace the door(s) on the unit, and turn the power back on. STEP 5 : Check Your Results. If the unit takes a few extra sec
