BORDSTRACT Digital PID Temperature Controller REX C100 AC100 240V
BORDSTRACT Digital PID Temperature Controller REX C100 AC100 240V
Key features
- Complete 3 Piece Temperature Control Set – This kit includes a REX-C100 digital controller, a K-type thermocouple, and a 25A solid-state relay. Designed for reliable and sturdy performance, it provides all the essential components for precise temperature management in industrial and laboratory applications.Controller size: 48x48x110mm/1.9x1.9x4.3in .
- High Precision Digital PID Controller – The REX-C100 features ±0.5% FS measurement accuracy and a 14-bit resolution with a 0.5 second sampling cycle. It supports ON/OFF, step-type PID, and continuous PID control modes with self-tuning capability for optimized temperature regulation.
- Clear LED Display with Easy Monitoring – Process value, set value, output status, alarm, and self-tuning indicators are clearly shown on the bright LED display. This makes reading and adjusting parameters simple and convenient during operation.
- K Type Thermocouple with Solid State Relay – The included K-type thermocouple has a 0-400°C range with 1m fiberglass insulated cable. The 25A solid-state relay ensures reliable switching for heating elements. Package includes controller, thermocouple, and relay.
- Versatile Compatibility for Various Equipment – This thermostat is widely used in power systems, injection molded, food processing, incubators, ovens, and more. Its professional self-tuning PID technology ensures fast temperature control, quick response, and high precision with ultra-low adjustment.
Features: temperature control three-piece set, sturdy and reliable. Digital temperature controller has and good sensitivity. PIN control including ON/OFF, step-type PID and continuous PID. and simple operation, . LED display screen for clear reading.Specification:Condition: 100% Weight: 239g/8.4ozREX - C100 thermostat:Model: REX-C100FK02-V*AN DNMeasurement accuracy: ±0.5% FSEnd to end compensation tolerance: 0 ~ 50 ℃ can be through the software to modify + 2 ℃Resolution: 14 bitsSampling cycle: 0.5 secondsProcess value: (PV) Set value: (SV)Output, alarm and self-setting indicate: by LEDPIN control: including ON/OFF, stepper PID and continuous PIDSelf-adjusting control: YesAlarm function output: NoProportional band (P) : 0 ~ full range (ON/OFF control set to 0)The testing temperature range: 0 ~ 400 ℃Insulation resistance: > 50M ohm (500V DC)Insulation resistance: 1500V AC/minInsulation resistance: power consumption The environment of service: 0 ~ 50 ℃Non-corrosive gas environment 30 ~ 85% RHTemperature input type: K-type thermocoupleSize: 48 * 48 * 110mm / 1.9 * 1.9 * 4.3inK Type Thermocouple:Length: 1mDiameter of sensor: 4.5mmTemperature range: 0 ~ 400 ℃Internal insulation: fibergl
Free shipping included. 30-day hassle-free returns.
