CBB65A 35+5 MFD Dual Run Capacitor, Round

Key features

• ✅ Dual Run Capacitor: Features 35+5 MFD (35/5F) capacitance rating with 6% tolerance, designed to power both the compressor and fan motor simultaneously in your air conditioning system for efficient operation
• ✅ Wide Voltage Range: Operates reliably across 370-440VAC, making it compatible with various residential and commercial HVAC systems and providing flexibility for different electrical configurations
• ✅ CBB65A Construction: Built with metallized polypropylene film technology in a round aluminum shell design that offers durability and heat dissipation for consistent performance in demanding cooling applications
• ✅ Direct Replacement Part: Designed as a replacement capacitor for condenser units, compressor motors, and fan motors in air conditioning systems, helping restore proper function to your HVAC equipment
• ✅ Compact Round Design: Features a space-efficient cylindrical shape that fits standard mounting brackets and terminal configurations, simplifying installation in tight equipment compartments
• ✅ **2-in-1 Dual Run AC Capacitor for HVAC Condenser** CBB65A round dual run capacitor powers both your AC compressor (Herm) and condenser fan motor in one unit. Available in 35+5μF,40+5μF,45+5μF with **±6% capacitance tolerance**. Rated for 370‑440VAC, compatible with 60Hz US residential HVAC systems. Direct drop-in replacement for most air conditioners & heat pumps. Physical size: Φ50mm × 105mm height.
• ✅ **Heavy-Duty Aluminum Shell & Eco Vegetable Oil Filled, No PCB** Built with high purity Zn-Al metallized polypropylene film. Sealed aluminum alloy housing provides superior heat dissipation. Filled with eco-friendly vegetable oil with **zero PCB**. 10,000 AFC explosion-proof safety protection. Ultra-low dissipation factor, reduces overheating and extends service life during continuous outdoor operation.
• ✅ **Extreme Wide Temperature Rating for Outdoor Units** Operating temperature range: -40℃ ~ 85℃ (-40℉ to 185℉). Withstands blazing summer heat and freezing cold winter for outdoor condenser cabinets. Strict factory high voltage testing, prevents breakdown or flashover under harsh weather conditions.
