CNCTOPBAOS 5 Axis CNC Controller System Offline Standalone DDCS Expert V2.1

5 Axis CNC Controller System Offline Standalone DDCS Expert V2.1

Key features

• Product: 5-Axis DDCS-Expert Controller; Model: DDCS-Expert; Support Axis: Max. 5 Axis; 1MHz 1000KHz output frequency for each axis; 7 inch full color display screen; resolution ratio: 1024x600, 40 operation keys
• Introduction: The DDCS Expert numerical control system adopts the ARM and FPGA design framework,ARM controls the human-computer interface and code analysis and the FPGA provides the underlying algorithms and creates the control pulse; The internal operating system is Linux based
• Main Features: 24 photoelectric isolated digital inputs, 21 photoelectric isolated digital outputs;Analog spindle control 0-10V spindle control, also support PWM Output; Compatible with standard G-code,support popular CAD/CAM software, such as ArtCam, MasterCam, ProE, JDSoft SurfMill, Aspire, Fusion 360 and so on
• More Features: Magazine type: Supports multiple spindle mode, support straight Tool Magazine, gantry type Magazine, disk type magazine; Probe Mode: Supprt Floating Probe and Fixed Probe; Backlash compensation methods: direction gap compensation, radius gap compensation, length compensation;The control system can preview the processing path before machining, and it makes the system more steady, working smoothy and precise etc
• Applications: The DDCS Expert can be used for many styles and types of CNC router,Engraver machines,Milling machine,Cutting machine,Lathes, CNC Routers,Pick and Place and Driling Machine, lathe and cutters are just a few examples
