Dayton 1/3 HP General Purpose Motor,3-Phase,1765 Nameplate RPM,Voltage 230/460,Frame 56C

Description Motor complies with 2015 efficiency legislation for small-frame motors. Item: General Purpose Motor Motor Application: General Application Motor Design: 3-Phase Motor Enclosure Design: Open Dripproof HP: 1/3 Nameplate RPM: 1765 Frame: 56C Voltage: 230/460 Hz: 60 Phase: 3 Full Load Amps: 1.3/0.68 No. of Speeds: 1 Motor Mounting Type: Face Motor Mounting Position: Horizontal Motor Thermal Protection: None Ins. Class: F Motor Service Factor: 1.35 Motor Bearings: Ball Motor Frame Material: Rolled Steel Max. Ambient Temp.: 40 Degrees C Motor Shaft Rotation: CW/CCW Shaft Dia.: 5/8" Shaft Length: 1-7/8" Length Less Shaft: 7-1/8" Overall Length: 10-5/16" Motor Shaft Design: Keyed RPM Range: 1701-1800 Standards: UL, CSA, CE Duty: Continuous Motor Efficiency Group: Premium Efficient Nominal Efficiency: 73.4% Inverter Rated: Yes Includes: MIMI 8S470A & Shaft Key Manufacturers Warranty Length: 1 yr. RPM Group: 1701-1800 Green Environmental Attribute: Product Contributes To Reducing Energy Consumption Green Certification or Other Recognition: NEMA Premium Rated
