Dwyer Visi-Float Flowmeter, VFA-2-SSV, Acrylic Block, 5% FS Acc, .2-2 SCFH air, SS Valve

Key features

• MANUFACTURER DIRECT
• Temperature & Pressure Limits: Without Valve: 100 psig (6.9 bar) @ 150°F (65°C); 150 psig (10 bar) @ 100°F (38°C); With Valve: 100 psig (6.9 bar) @ 120°F (48°C).
• Process Connection: 1/8" female NPT.
• Service: Compatible gases and liquids.
• Scale Length: VFA 2" typical length; Mounting Orientation: Mount in vertical position.

The Dwyer Visi-Float series VFA flowmeter is a 2" scale air flow meter with 1/8" female NPT inlet and outlet connections for inline monitoring and measuring of air flow with an accuracy of + or – 5% of full scale, and is precision machined from solid acrylic plastic to resist breakage and provide a clear view of the scale. Black scale graduations are hot-stamped into the plastic for distinct readings. This lightweight flowmeter has a metal mounting insert for panel mounting and can also be supported directly by system piping. Models are available for measuring air flow in scfh or lpm. Some models come with a brass or stainless steel metering valve for precise adjustment of air flow. Inlet and outlet connections are brass except for models with stainless steel wetted parts and the connections are on the back of the flowmeter except for models that have end connections. This flowmeter is commonly used for measuring air flow in medical equipment, air samplers, gas analyzers, pollution monitors, chemical injectors, and cabinet purging equipment, among other devices.SpecificationsScale length2" (on average)Accuracy+ or – 5% of full scaleConnections1/8" female NPT inlet and outletPressur
