ELECTRONICS-SALON Passive Bistable/Latching DPDT 8 Amp Power Relay Module, 12V Version
ELECTRONICS-SALON Passive Bistable/Latching DPDT 8 Amp Power Relay Module, 12V Version
Key features
- Passive Bistable/Latching DPDT 8 Amp Power Relay Module.
- 12V version, model number: MD-D262/12V.
- HF115F-L high quality bistable relay.
- High quantity terminal blocks, easy connection wires.
- FR-4 Fiber glass PCB.
Passive Bistable/Latching DPDT 8 Amp Power Relay Module. 12V version, model number: MD-D262/12V. Datasheet: http://www.audiowind.com/pdf/D-262to264.pdf, no paper specifications, please download this document. The item has been assembled, and electrical test passed. HF115F-L high quality bistable relay. Relay coil protection by means of freewheeling diodes. High quantity terminal blocks, easy connection wires. FR-4 Fiber glass PCB. Terminal block specifications: Wire range: 24 ~ 12 AWG. Strip length: 7mm. Screws - M2.5, steel, Cr3+ Zn plated. Pin header and Cage - Brass
Free shipping included. 30-day hassle-free returns.
