MAKERELE NEMA 17 NEMA 23 Stepper Motor Driver Controller, Integrated Module

NEMA 17 NEMA 23 Stepper Motor Driver Controller, Integrated Module

Key features

• 2 in 1 Integrated Stepper Motor Controller & Driver: Combines stepper motor controller and driver into one compact unit, directly connectable to stepper motors without extra modules. Features input reverse polarity protection for safe operation, and supports 1-128 microstep resolution for high-precision motion control.
• Flexible Forward & Reverse Rotation Control: Supports multiple ways to switch rotation direction: physical button operation, potentiometer adjustment, and automatic direction switching via preset working modes. Perfect for multi-scene applications with diverse motion requirements.
• 4-Way Control Modes & 9 Built-in Working States: Features 4 flexible control methods: built-in parameter mode, external button control, external driver linkage, and UART serial command control. Pre-programmed with 9 default workflows including forward/reverse, delay, loop, self-locking, speed regulation, covering most automation scenarios.
• LCD Display with Parameter Memory Function: High-definition LCD screen intuitively shows motor speed, delay time, cycle counts and other key data for high‐precision motion control. All set parameters are automatically saved and will not be lost after power-off.
• Wide Compatibility & Multiple Adjustable Functions: Works with DC 10-30V two-phase 4-wire/5-wire/6-wire/8-wire stepper motors. Ideal for CNC equipment, DIY automation and various motor control projects.
