Pneumatic Rodless Cylinder 40mm Bore 600mm Stroke
Pneumatic Rodless Cylinder 40mm Bore 600mm Stroke
Key features
- Save Installation Space: Compared to regular cylinders, the installation space of rodless cylinders can be reduced by half at the same stroke
- Optional Air Connection Position: The end cap can be rotated 4x90 degrees(only for DP16-40 series), making it flexible to install. Unique multiple air connection option and optional positions for air inlet and outlet, allowing for the same end or both ends of air inlet and outlet
- Sturdy & Durable: The rodless cylinder equipped with metal sealing strips and rubber sealing rings has excellent sealing performance. Full hard oxidation shell features high strength and corrosion resistance, increasing the cylinder's lifespan
- Provide Customization Service: The stroke, the bore and the air connection position can be customized according to your demands.
- Easy to install: The aluminum anodized slider can be installed on three sides, which makes it easy to install and operate
This pneumatic rodless cylinder features a 40mm bore diameter and 600mm stroke length, designed for mechanical double acting operation at 8bar pressure. The innovative rodless design reduces installation space requirements by half compared to traditional cylinders with equivalent stroke lengths. Constructed with a full hard oxidation aluminum shell, the cylinder offers high strength and corrosion resistance for extended service life. The sealing system incorporates metal sealing strips and rubber sealing rings to ensure excellent sealing performance during operation. The aluminum anodized slider provides three-sided installation options for flexible mounting configurations. The end cap design allows for rotation in 4x90 degree increments on DP16-40 series models, offering versatile air connection positioning. Air inlet and outlet ports can be configured at the same end or at both ends to accommodate various installation requirements. The cylinder supports customization options for stroke length, bore size, and air connection positions to meet specific application needs. This rodless cylinder is suitable for material handling applications where space efficiency and reliable pneumati
