RackSolutions 1U 2Post Universal Rack Rail with Cable Wirebar

Key features

• Fits any 2Post rack: supports square and round hole racks in 10-32, 12-24 and metric M6 threads
• Capacity by rack unit: rated 45 lbs and 75 lbs for 1U devices and up to 200 lbs for 3U devices
• Adjustable mounting depth: sets from 10in to 31.75in, 254 to 806 mm, for center or flush mounting
• Cable management built in: an integrated wirebar and hook-and-loop straps keep cabling dressed behind the equipment
• OEM rail alternative: works with Dell, HP and IBM servers and ships with screws, cage nuts and nuts for every rack type

The RackSolutions 1U 2Post Universal Rack Rail is a general purpose mounting rail for standard 19in server racks, built for IT teams that would rather stock one rail than a different OEM kit for every chassis. It mounts in any 2Post rack and supports square and round hole racks in 10-32, 12-24 and metric M6 threads. Load rating runs from 45 lbs and 75 lbs for 1U devices up to 200 lbs for 3U devices, and mounting depth adjusts from 10in to 31.75in, 254 to 806 mm, in either a center or a flush configuration. An integrated cable management wirebar and hook-and-loop straps keep cabling dressed behind the equipment instead of draped across the rear of the rack. The rail carries a zinc plated finish and ships with screws, cage nuts and nuts covering every rack type, so nothing else is needed to complete the install.
