UST1152 1.5HP Pool Pump Motor Compatible with Century/A.O. Smith, SP2610X15

Key features

• Exact OEM‑Fit Replacement Motor: Our UST1152 pool pump motor achieves 1:1 dimensional and performance compatibility with A.O. Smith Century UST1152. It serves as a direct drop‑in replacement for Hayward SP2610X15, US Motors AST165 and A.O. Smith B229.
• Works seamlessly with Hayward Super/Super II/Max‑Flow, Jacuzzi Magnum, Pinnacle 1.5HP pool pump assemblies. Zero extra alterations or machining required during installation.
• Precise Core Specs: Single‑speed motor with switchable 115/230V dual voltage, max amps: 9.3A@230V /18.6A@115V, 3450 RPM, 56J frame, SF=1 service factor & Class B insulation. Continuous‑duty (CONT) construction withstands 50°C ambient temperature for consistent daily pool circulation.
• Outdoor‑Ready Build for Superior Long‑Term Reliability: Built for higher reliability, it features a 5/8" 1045 steel threaded shaft with great load‑bearing and wear resistance. Four 3/8" 360° evenly‑spaced threaded mounting holes ensure solid installation. Weather‑resistant housing and integrated pedestal base resist harsh outdoor conditions, reduce breakdown chances and prolong motor service life.
• Stable Power, Superior Durability & Built‑In Safety: Boasting great durability, this capacitor‑start motor provides high‑torque, consistent power to lift pool flow rate and circulation pressure. Integrated automatic thermal protection cuts power during overheating to prevent burnout. Safe for long‑term use, suitable for home outdoor pools, public pools and inflatable pools.
• Easy Install, Quiet Running & Professional Service: Simplified design supports quick installation and easy maintenance. Optimized for quiet operation to reduce working noise. Comes with clear dual‑voltage wiring guidelines; adjust wiring per the diagram for your power supply. 24‑hour customer service available. Get timely replies from our specialists for questions about model fit, installation or operation.

Free shipping included. 30-day hassle-free returns.
