HVAC Motor 1/30 HP 1550 RPM 115V 3.3

Key features

• General Purpose Fan Motors
• HP: 1/30
• RPM: 1500
• Volts: 115

Rugged, single-phase motor is designed for use in air-moving or mechanical applications, including fans, HVAC, pumps, and compressors. Item: HVAC Motor Motor Design: Shaded Pole HP: 1/30 RPM Range: 1501-1600 No. of Speeds: 1 Voltage: 115 Motor Shaft Rotation: CCWSE Motor Enclosure Design: Open Dripproof Motor Mounting Type: Stud Shaft Dia.: 5/16" Shaft Length: 2-1/4" Number of Shafts: 1 Motor Thermal Protection: Auto Nameplate RPM: 1550 Phase: 1 Motor Application: HVAC/R Motor Sub Application: Direct Drive Fan/Blower Frame: 3.3 Motor Bearings: Sleeve Full Load Amps: 1.3 Duty: Continuous Motor Service Factor: 1.00 Hz: 60 Body Dia.: 3.3" Ins. Class: B Max. Ambient Temp.: 40 Degrees C Length Less Shaft: 2-5/8" Mounting Stud Location: 4/Both Ends Stud/Base Mtg. Pattern: 2-7/8" x 2-7/8" Motor Shaft Design: Flat Application: HVAC/R Mounting Pattern: 2-7/8 x 2-7/8
